Battery4000Wh
Top speed90 km/h
Range120-250 km (75-155 mi)
Weight46.2 kg
Specs
- Status
- active
- Released
- 2024
- Voltage
- 151V
- Motor
- 3200W
- Peak
- 8000W
- BMS
- Smart
- Max load
- 145 kg (320 lbs)
- Size class
- 20"
- Rim
- 14"
- Tire
- 80/90-14
- Similar tire sizes
Stock: 80/90-14metric · 80mm · 19.7" OD
Closest
Best geometry match, still verify the exact tire model.- 3-14closest geometryinch-rim · 76mm · 20.0" OD · +0.3" ODsame rimclosesttallerSearch web
Possible
Close enough to research, but expect handling or clearance changes.- 2.75-14narrower tireinch-rim · 70mm · 19.5" OD · -0.2" ODsame rimsimilar ODnarrowerhandling changeSearch web
- 70/90-14narrower and lowermetric · 70mm · 19.0" OD · -0.7" ODsame rimnarrowerlowerhandling changeSearch web
- 90/90-14wider and tallermetric · 90mm · 20.4" OD · +0.7" ODsame rimwidertallerhandling changeSearch web
- 3.25-14taller tireinch-rim · 83mm · 20.5" OD · +0.8" ODsame rimtallerhandling changeSearch web
- 80/100-14taller tiremetric · 80mm · 20.3" OD · +0.6" ODsame rimtallerhandling changeSearch web
- 80/80-14lower tiremetric · 80mm · 19.0" OD · -0.6" ODsame rimlowerhandling changeSearch web
- 90/80-14wider tiremetric · 90mm · 19.7" OD · 0.0" ODsame rimsimilar ODwiderhandling changeSearch web
Measure first
Higher fitment risk. Check shell clearance before buying.- 2.5-14narrower and lowerinch-rim · 64mm · 19.0" OD · -0.7" ODsame rimnarrowerlowerverify clearanceSearch web
- 100/90-14wider and tallermetric · 100mm · 21.1" OD · +1.4" ODsame rimwidertallerverify clearanceSearch web
Calculated from rim, width, and outer diameter overlap. Verify shell clearance, bead fit, tube/tubeless setup, and load rating before buying.
- Suspension
- 90mm, fully hydraulic fork (FastAce)
- Waterproofing
- IPX6
- Charging
- 2 ports, 5A stock, 20A max
- Price
- €3,800 / $4,200
- MOSFETs
- 36
Aliases: Sherman L
Best use
- Long distance
- High-speed cruising
- All-day riding
555 notes
50% more battery than Lynx at only 14.5lb more weight. Same proven Lynx controller. eWheels lists Sherman-L as capable of hall-less operation from a complete stop. Supports 20A fast charging.
